70-784D14-1 by schneider electric-legacy relays
Image is representational - see manufacturer specifications
Schneider Electric-Legacy Relays Authorized Distributor

70-784D14-1

Socket - SE Relays general purpose relay accessory - 4PDT - 16A - 300 V - 14 pins - screw clamping terminal - 784 series ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

The Magnecraft / Schneider Electric part 70-784D14-1 is a reliable and durable connection relay socket. With a 14 position screw terminal and panel mount design, it is perfect for securely mounting and connecting relays in various applications. This high-quality socket is designed for easy installation and provides efficient and stable connections for optimal performance.

Search Keywords: 70784D141

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
70-784D14-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Type:
Relay Socket
Number of Contacts:
14
Maximum Voltage Rating:
300 V
Maximum Current Rating:
16 A
Mounting:
Panel Mount
Operating Temperature:
-40 to 80 °C
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is 70-784D14-1 discontinued?

Yes, 70-784D14-1 from Schneider Electric-Legacy Relays is discontinued (end-of-life March 2026). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is 70-784D14-1 RoHS compliant?

Yes, 70-784D14-1 is RoHS compliant.

What is the lead time for 70-784D14-1?

The standard lead time for 70-784D14-1 is approximately 2 weeks. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 323

Ships today, if you order in

Minimum Order Quantity: 10

Multiple: 10

Price (USD)

Qty
Unit Price
10
$16.71
30
$16.36
50
$15.87
100
$15.08
250
$14.43
500
$14.35
1,000 +
$14.28
