389FXBXC1-24D by schneider electric-legacy relays

389FXBXC1-24D

Schneider Electric-Legacy Relays

Power relay - SE Relays - DPDT - 25A - 24 VDC - side flange cover ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Magnecraft / Schneider Electric part 389FXBXC1-24D is an electromechanical relay designed for various power control applications. It operates on a 24VDC power supply and has a coil resistance of 400 Ohm. This relay can handle up to 13A DC or 25A AC current, making it suitable for both low and high-power circuits. The DPDT (Double Pole Double Throw) configuration allows for versatile switching options. With dimensions of 73.82x38.89x35.72mm and a flange design, it can be easily mounted on a panel or other surfaces. The 389FXBXC1-24D relay delivers reliable and efficient performance, making it an excellent choice for numerous industrial and commercial applications.

Search Keywords: 389FXBXC124D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
389FXBXC1-24D
Alias/AKA:
W389FXBXC1-24D
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
25 A
Mounting:
Flange Mount
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 55 °C

IN STOCK: 663

Can Ship immediately

Factory Lead-Time 9 Weeks

Qty
Unit Price
1
$41.82
10
$35.86
30
$35.68
50
$35.50
100
$35.11
250
$34.94
500 +
$34.76
Suppliers Standard Package
Log in for special pricing
