TSW-110-07-G-S by samtec

TSW-110-07-G-S

Samtec

Board-To-Board Connector - 2.54 mm - 10 Contact - Header - Through Hole - 1 Row. ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TSW series from Samtec are standard terminal strip headers. These are unshrouded through hole headers with 0.025" (0.635mm) square post and mates with Samtec SSW, SSQ, SSM, ESW, ESQ, BCS, BSW, CES, SLW, IDSD, IDSS, SMSD and SMSS series of connectors. TSW series connectors are available with industry's largest variety of standard pin counts, terminal lengths and are used where signal integrity and reliability is of major concern.

Search Keywords: TSW11007GS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
TSW-110-07-G-S
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
550 VAC
Maximum Current Rating:
6.3/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 925

Can Ship immediately

Manufacturer Stock: 946   can ship 12/1/25

Minimum Order: 25

Factory Lead-Time 2 Weeks can ship 12/3/25

Qty
Unit Price
25
$1.0210
250
$0.7530
500
$0.6180
1,000
$0.4912
2,500
$0.4546
5,000
$0.4523
7,500
$0.4501
10,000 +
$0.4478
