TSM-106-01-L-SV by samtec
Image is representational - see manufacturer specifications
Samtec Authorized Distributor

TSM-106-01-L-SV

Board-To-Board Connector - 2.54 mm - 6 Contacts - Header - Surface Mount - 1 Row. ...

View Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TSM-106-01-L-SV is a 6-pole 1-row 2.54mm Surface Mount Terminal Strip with 10µinch (0.25µm) gold-plated phosphor bronze contacts, matte tin plated tail and LCP insulator. The TSM series vertical pin terminal strip is compatible with BCS, BSW, CES, ESQ, ESW, HCSD, HCSS, HLE, IDSD, IDSS, ISDM, ISSM, MNT, PHF, SLW, SMH, SMSD, SMSS, SNT, SSM, SSQ and SSW series connectors. Designed specifically for surface mount applications with many options to facilitate processing.

Search Keywords: TSM10601LSV

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
TSM-106-01-L-SV
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Tube
Type:
Unshrouded Header3594
Body Orientation:
Straight3574
Gender:
HDR3578
Mounting:
Surface Mount3586
Pitch:
2.54 mm
Number of Contacts:
6
Maximum Voltage Rating:
4753584VAC
Maximum Current Rating:
5.4/Contact A
Termination Method:
Solder3593
Operating Temperature:
-55 to 125 °C

FREQUENTLY ASKED QUESTIONS

Is TSM-106-01-L-SV RoHS compliant?

Yes, TSM-106-01-L-SV is RoHS compliant.

What is the lead time for TSM-106-01-L-SV?

The standard lead time for TSM-106-01-L-SV is approximately 3 days. In-stock quantities ship from Master Electronics.

IN STOCK: 5,164

Can Ship immediately

Minimum Order Quantity: 50

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
50
$0.7619
250
$0.4990
1,000
$0.4265
2,500
$0.4156
5,000
$0.3434
7,500 +
$0.3278
Log in for special pricing Click for Quote Price Match Request
