ESQ-105-14-G-D by samtec
Image is representational - see manufacturer specifications
Samtec Authorized Distributor

ESQ-105-14-G-D

Board-To-Board Connector - Elevated - 2.54 mm - 10 Contacts - Receptacle - Through Hole. ...

View Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The ESQ series from Samtec are PC/104 through hole elevated socket strips. It mates with Samtec TSW, MTSW, EW, MTLW, TSS, ZSS, TSM, DW, ZW, HW, TSSH and HTSS series of connectors. These are self nesting socket strips which has standard and low insertion force contacts with 0.025" (0.635mm) square tail.

Search Keywords: ESQ10514GD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
ESQ-105-14-G-D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Tube
Type:
Elevated Socket
Body Orientation:
Straight
Gender:
SKT
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
550 VAC
Maximum Current Rating:
5.7/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

FREQUENTLY ASKED QUESTIONS

Is ESQ-105-14-G-D RoHS compliant?

Yes, ESQ-105-14-G-D is RoHS compliant.

What is the lead time for ESQ-105-14-G-D?

The standard lead time for ESQ-105-14-G-D is approximately 2 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1,970

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
10
$3.84
50
$2.68
250
$2.38
500
$2.02
1,000
$1.99
2,500
$1.89
5,000
$1.88
7,500 +
$1.87
Log in for special pricing Click for Quote Price Match Request
