MD-30SG by same sky®’s
Image is representational - see mfr. specs

MD-30SG

Same Sky®’s

3 Pin - Mini Circular Connector - Fully Shielded w/ Ground Tabs ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MD-30SG is a 3-pin Mini DIN connector designed for PCB mounting with right-angle orientation and full electromagnetic shielding. It features a fully shielded design with ground tabs for enhanced signal integrity and operates at rated input voltages of 100 Vac or 12 Vdc with a maximum input current of 2 A. The connector exhibits excellent electrical performance with contact resistance of 30 mO maximum, insulation resistance of 50 MO at 250 Vdc, and voltage withstand capability of 250 Vac for 1 minute. With an operating temperature range of -40°C to +85°C, insertion force between 1–4.5 kg, and a rated life of 1,000 cycles, the MD-30SG is well-suited for industrial control systems, audio equipment, and data communication applications requiring robust, shielded interconnections.

Search Keywords: MD30SG

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Same Sky®’s
Part No:
MD-30SG
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Box

IN STOCK: 2,373

Can Ship immediately

Minimum Order Quantity: 52

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
52
$1.48
600
$1.19
2,000
$1.14
3,000
$1.13
10,000 +
$1.12
Log in for special pricing Click for Quote Price Match Request
