Image is representational - see mfr. specs

3021023-16

The 3021023-16 is a 16-foot USB cable assembly featuring a Type-A male connector on one end and a blunt, unterminated cut on the other. ...

Datasheet

RoHS Compliant

Carton Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 3021023-16 is a USB pigtail cable assembly designed for custom wiring applications. This 16-foot (4880mm) cable features a gold-plated USB Type-A male connector on one end and a blunt cut on the other, exposing the internal wires for termination. The cable is constructed using UL2725 24/26AWG wire with a black PVC outer jacket that has an outer diameter of 4.5mm. Key electrical specifications include a maximum conductor resistance of 3 ohms and a minimum insulation resistance of 10 MΩ at 400V DC. This RoHS compliant cable is ideal for prototyping, repair, or creating custom USB connections in various electronic systems.

Product Highlights:

Potential Applications:

Search Keywords: 302102316

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Qualtek Electronics

Part No:

3021023-16

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544422000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
