PA2454NLT by pulse electronics
Image is representational - see mfr. specs

PA2454NLT

Pulse Electronics

The PA2454NLT is a surface-mount, high-frequency wire-wound flyback transformer designed for power applications up to 30W. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PA2454NLT is a high-frequency, surface-mount flyback transformer from the EP10 platform, designed for power applications up to 30W. It features a primary inductance of 24µH, a maximum leakage inductance of 0.75µH, and a primary DC resistance of 82 mΩ maximum. This component ensures high isolation with a primary-to-secondary Hi-Pot rating of 1500 Vrms and is designed to operate over a wide temperature range from -40°C to +130°C. This transformer is optimized for flyback converter topologies with a 20-30V input and a 250 kHz switching frequency, making it ideal for power supplies requiring multiple outputs.

Search Keywords: PA2454NLT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Pulse Electronics
Part No:
PA2454NLT
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504504000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
200
Package Type:
REEL

IN STOCK: 790

Ships today, if you order in

You may purchase all in-stock quantity of 790

Stock lot only: 790

MOQ for In Stock Qty: 1200

MOQ for out of Stock Qty: 1200

Multiple: 200

Factory Lead-Time 9 Weeks

Qty
Unit Price
300
$3.61
600
$2.22
900
$1.75
1,200 +
$1.72
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
