P0502NLT
The P0502NLT is a surface-mount (SMT) common mode choke featuring a 470 µH inductance and a 12 A current rating. ...
DESCRIPTION
The P0502NLT is a surface-mount common mode choke from the HCCI-80 series designed for high-current applications. It provides a nominal inductance of 470 µH and supports a rated current of 12 A. Key electrical characteristics include a low DC resistance of 8 mOhms maximum per winding, a typical self-resonant frequency of 2.5 MHz, and a voltage rating of 600 Vdc. This component is designed to operate across a temperature range of -40°C to +125°C and has a dielectric strength of 1500Vrms. Its robust specifications make it suitable for power line filtering and EMI suppression in demanding electronic systems.
Search Keywords: P0502NLT
SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Is P0502NLT RoHS compliant?
Yes, P0502NLT is RoHS compliant.
What is the lead time for P0502NLT?
The standard lead time for P0502NLT is approximately 18 days. In-stock quantities ship from Master Electronics.
IN STOCK: 825
Can Ship immediately
On Order:
750
can ship 9/14/26
Minimum Order Quantity: 75
Multiple: 75
Factory Lead-Time 18 Weeks
Datasheet
