J0G-0001NL by pulse electronics
Image is representational - see manufacturer specifications
Pulse Electronics Authorized Distributor

J0G-0001NL

The J0G-0001NL is a 100/1000Base-T single-port (1x1) RJ45 Tab-UP connector with integrated magnetics. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The J0G-0001NL is a low-profile, single-port 100/1000Base-T RJ45 connector with integrated magnetics. It is designed to be compliant with the IEEE 802.3 standard and features a minimum Open Circuit Inductance (OCL) of 350µH with an 8mA bias current. Key electrical specifications include an insertion loss of -1.2 dB, a Hipot rating of 1500Vrms, and an operating temperature range of 0°C to +70°C. With its low height, small footprint, and high performance for EMI suppression, this connector is ideal for space-constrained applications such as Network Interface Cards (NIC), LAN-on-Motherboard (LOM), and PC applications.

Search Keywords: J0G0001NL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Pulse Electronics
Part No:
J0G-0001NL
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536698000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
70
Package Type:
TRAY
Type:
RJ-45
Body Orientation:
Right Angle
Mounting:
Through Hole
Pitch:
2.03 mm
Gender:
F
Number of Contacts:
8
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is J0G-0001NL RoHS compliant?

Yes, J0G-0001NL is RoHS compliant.

What is the lead time for J0G-0001NL?

The standard lead time for J0G-0001NL is approximately 9 days. In-stock quantities ship from Master Electronics.

IN STOCK: 715

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$8.13
25
$7.77
70
$7.40
140
$7.09
280
$6.98
560
$6.96
1,050 +
$6.94
Supplier's Standard Package
