RV4NAYSD752A

The RV4NAYSD752A is a MIL-style RV4 precision potentiometer with a resistance of 7.5 kΩ, a linear taper, and a slotted shaft. ...

Datasheet

RoHS Compliant

DESCRIPTION

The RV4NAYSD752A is a MIL-style RV4 series precision potentiometer designed for military and commercial applications. This component has a total resistance of 7.5 kΩ with a linear taper and ±10% tolerance, and a power rating of 2 watts at 70°C. It is constructed with a hot molded carbon element, gold-plated terminals, and a stainless-steel shaft and housing for durability. The device features a standard bushing, a slotted 7/8-inch shaft, and is rated for a rotational life of 25,000 cycles. Its robust design, meeting MIL-R-94 standards and operating from -65°C to +125°C, makes it ideal for demanding environments requiring high reliability.

Product Highlights:

Potential Applications:

Search Keywords: RV4NAYSD752A

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Precision Electronics

Part No:

RV4NAYSD752A

Alias/AKA:

KU7521S28-D

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8205595560

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
