3273362

Phoenix Contact

A brown distribution block with 13 push-in connections for power distribution, rated for 500 V and 24 A. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 3273362 is a basic distribution block with a supply connection, designed for efficient power distribution. It features 13 tool-free push-in connections that accommodate a conductor cross-section range of 0.14 mm² to 4 mm² (AWG 26-12). The block is rated for a nominal voltage of 500 V and a nominal current of 24 A, with a maximum load current of up to 57 A possible with a 10 mm² conductor. Made from brown polyamide (PA) with a UL 94 V0 flammability rating, it offers flexible mounting options including DIN rail adapters, direct mounting, or adhesive mounting. This ready-to-mount block saves installation time and up to 50% space on the DIN rail due to its transverse design, making it ideal for clear wiring in control cabinets.

Product Highlights:

Potential Applications:

Search Keywords: 3273362

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

3273362

Alias/AKA:

PTFIX-6/12X2-5-BN

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
