3273224

Name: 3273224 Phoenix Contact DIN Rail Terminal Blocks
Brand: Phoenix Contact
SKU: 50078619
Availability: InStock

Distribution block - Block with horizontal alignment and integrated supply - The blocks can be bridged with one another via the conductor shaft. For corresponding plug-in bridges - see accessories - nom. voltage: 690 V - nominal current: 24 A - connection method: Push-in connection - Push-in connection - number of connections: 13 - cross section: 0.14 mm² - 4 mm² - AWG: 26 - 12 - width: 41 mm - color: red - mounting type: NS 35/7,5 - NS 35/15 ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The Phoenix Contact part 3273224 is a distribution block designed with horizontal alignment and integrated supply. These blocks can easily be bridged with one another using the conductor shaft. It has a nominal voltage of 690V and a nominal current of 24A, making it suitable for various electrical applications. The block features 13 connections with a push-in connection method, accommodating a cross-section range of 0.14mmÂ² to 4mmÂ² (AWG 26-12). The width of the block is 41mm and comes in a vibrant red color. It is designed for mounting on NS 35/7.5 or NS 35/15 rails. For additional functionality, plug-in bridges are available as accessories.

Product Highlights:

Potential Applications:

Search Keywords: 3273224

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

3273224

Alias/AKA:

PTFIX-6/12X2-5-NS35A-RD

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
