3033171 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

3033171

The 3033171 is a double-level ground terminal block featuring four connections with both spring-cage and screw termination methods for DIN rail mounting. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

The 3033171 is a double-level, green-yellow ground terminal block designed for versatile wiring applications. This terminal block provides a total of four connections across two levels, utilizing a combination of spring-cage and screw connection technologies. The spring-cage side accepts conductors from 0.08 mm² to 6 mm², while the screw connection side accepts conductors from 0.14 mm² to 6 mm². It is rated for a maximum load current of 36 A and a surge voltage of 6 kV, with a compact width of 6.2 mm. Its design allows for bridging across both levels, making it ideal for implementing complex switching tasks in space-constrained control cabinets and industrial systems.

Search Keywords: 3033171

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
3033171
Alias/AKA:
STTBU-4-PE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
PL
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is 3033171 discontinued?

Yes, 3033171 from Phoenix Contact is discontinued. Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is 3033171 RoHS compliant?

Yes, 3033171 is RoHS compliant.

What is the lead time for 3033171?

The standard lead time for 3033171 is approximately 4 weeks. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 111

Can Ship immediately

Price (USD)

Qty
Unit Price
1
$13.73
50 +
$13.04
