Name: 3004100 Phoenix Contact Fuse Accessories
Brand: Phoenix Contact
SKU: 12156966
Availability: InStock

Fuse modular terminal block - fuse type: Glass / ceramics / ... - number of positions: 1 - connection method: Screw connection - cross section: 0.2 mm²- 4 mm² - AWG: 24 - 12 - nominal current: 6.3 A - nom. voltage: 800 V - width: 8.2 mm - fuse type: G / 5 x 20 / 5 x 25 / 5 x 30 - mounting type: NS 35/7,5 - NS 35/15 - NS 32 - color: black ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 3004100 is a 1-position fuse Terminal Block with PA (polyamide) insulator and black colour for cartridge fuse insert. 0.2 to 4mm² cross-section, 26 to 10AWG wire size and 8.2mm width, nein open side panel and screw wire connection method. UL94V-0 Flammability rating G/5 x 20/5 x 25/5 x 30 Glass fuse Versions with LED Large-surface labelling Safety lever locked in end position Applications Industrial

Product Highlights:

Potential Applications:

Search Keywords: 3004100

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

3004100

Alias/AKA:

UK-5-HESI

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99
