Image is representational - see mfr. specs

3001501

Phoenix Contact

The 3001501 is a gray, DIN rail mountable feed-through terminal block with a screw connection method. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 3001501 is a feed-through terminal block that provides two screw connections for wiring. It is rated for a nominal voltage of 800 V and a nominal current of 24 A. This terminal block accommodates a conductor cross-section ranging from 0.2 mm² to 4 mm² (AWG 24-12). Constructed from gray polyamide (PA) insulating material with a V0 flammability rating, the block has a compact width of 5.2 mm. Its universal foot allows for versatile mounting on NS 32, NS 35/15, and NS 35/7,5 DIN rails, making it ideal for various industrial control and potential distribution applications.

Product Highlights:

Potential Applications:

Search Keywords: 3001501

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

3001501

Alias/AKA:

UK-3-N

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
