2967112 by phoenix contact
Image is representational - see mfr. specs

2967112

Phoenix Contact

PLC-INTERFACE - consisting of PLC-BSC.../21 basic terminal block with screw connection and plug-in miniature relay with multi-layer gold contact - for mounting on DIN rail NS 35/7,5 - 2 PDTs - input voltage 24 V AC/DC

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

PLC-INTERFACE - consisting of PLC-BSC.../21 basic terminal block with screw connection and plug-in miniature relay with multi-layer gold contact - for mounting on DIN rail NS 35/7,5 - 2 PDTs - input voltage 24 V AC/DC

Search Keywords: 2967112

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2967112
Alias/AKA:
PLC-RSC-24UC/21-21AU
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
PLC Relay
AC Coil Voltage:
24 V
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
0.05 A
Mounting:
DIN Rail
Operating Temperature:
-25 to 60 °C
Dimension:
14 x 80 x 94 mm
Termination Style:
Screw Terminal
Coil Current:
17.5 mA
Contact Form:
2 Form C

IN STOCK: 0

On Order: 20   can ship 5/11/26

Factory Lead-Time 2 Weeks

Qty
Unit Price
1
$42.00
5 +
$39.90
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

FBST-500-PLC-BU

Continuous plug-in bridge - length: 500 mm - color: blue

FBST-6-PLC-BU

Single plug-in bridge - length: 6 mm - number of positions: 2 - color: blue

FBST-500-PLC-GY

Continuous plug-in bridge - length: 500 mm - color: gray

FBST-500-PLC-RD

Continuous plug-in bridge - length: 500 mm - color: red

PLC-ESK-GY

Power terminal block - for the input of up to four potentials - for mounting on NS 35/7.5

FBST-8-PLC-GY

Single plug-in bridge - length: 8 mm - number of positions: 2 - color: gray

PLC-ATP-BK

Separating plate - 2 mm thick - required at the start and end of a PLC terminal strip. Fur ...

ZB10/WH-100:UNBEDRUCKT

Zack marker strip - Strip - white - unlabeled - can be labeled with: CMS-P1-PLOTTER - PLOT ...

FBST-6-PLC-GY

Single plug-in bridge - length: 6 mm - number of positions: 2 - color: gray

FBST-14-PLC-BK

Single plug-in bridge - length: 14 mm - number of positions: 2 - color: black

NS-35/15-AL-UNPERF-2000MM

DIN Rail - 35mmx15mm - Unslotted - Aluminum - 2m

NS-35/15-PERF-2000MM

DIN Rail - 35mmx15mm - Slotted - 2m

NS-35/15-UNPERF-2000MM

The 1201714 is an unperforated, standard profile DIN rail made of galvanized steel, measur ...

ZB-10:UNBEDRUCKT

Zack marker strip - Strip - white - unlabeled - can be labeled with: PLOTMARK - CMS-P1-PLO ...

FBST-6-PLC-RD

The 2966236 is a red, 2-position single plug-in bridge designed for electrical connections ...

Show 13 More
