2966320 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

2966320

PLC-INTERFACE for input functions - consisting of PLC-BSC.../SEN basic terminal block with screw connection and plug-in miniature relay with multi-layer gold contact - for mounting on DIN rail NS 35/7,5 - 1 N/O contact - input voltage 120 V AC/110 V DC

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

PLC-INTERFACE for input functions - consisting of PLC-BSC.../SEN basic terminal block with screw connection and plug-in miniature relay with multi-layer gold contact - for mounting on DIN rail NS 35/7,5 - 1 N/O contact - input voltage 120 V AC/110 V DC

Search Keywords: 2966320

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2966320
Alias/AKA:
PLC-RSC-120UC/-1AU/SEN
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
PLC Relay
AC Coil Voltage:
120 V
DC Coil Voltage:
110 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
0.05 A
Mounting:
DIN Rail
Operating Temperature:
-25 to 55 °C
Dimension:
6.2 x 80 x 94 mm
Termination Style:
Screw Terminal
Coil Current:
3.5 mA
Contact Form:
1 Form A

FREQUENTLY ASKED QUESTIONS

Is 2966320 RoHS compliant?

Yes, 2966320 is RoHS compliant.

What is the lead time for 2966320?

The standard lead time for 2966320 is approximately 6 days. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 6   can ship 9/25/26

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$31.48
5 +
$29.91
Log in for special pricing Click for Quote Price Match Request
