1803594 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1803594

PCB connector - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 4 - pitch: 3.81 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 1803594 from Phoenix Contact is a 4 position pluggable terminal block with screw connection. This terminal block comes with 3.81mm pitch spacing and suitable for wire size ranging from 28AWG to 16AWG. Green colour insulation Tin contact surface Plug-in direction parallel and vertical to the PCB Individual position coding by removing the coding tab & connecting the coding profile to the header Polyamide (PA) insulating material UL94 V-0 flammability rating CSA, VDE, IECEE CB, CCA, EAC and cULus recognized Dimension of terminal block 16.1mm x 11.1mm x 16.03mm (L x H x W) Applications Industrial

Search Keywords: 1803594

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1803594
Alias/AKA:
MC-1-5/-4-ST-3-81
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
3.81 mm
Number of Circuits:
4
Maximum Voltage Rating:
160@IEC,300@UL V
Maximum Current Rating:
8 A
Wire Size:
16-28 AWG
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is 1803594 RoHS compliant?

Yes, 1803594 is RoHS compliant.

What is the lead time for 1803594?

The standard lead time for 1803594 is approximately 5 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 2,828

Can Ship immediately

On Order: 2,000   can ship 10/29/26

Minimum Order Quantity: 5

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
5
$4.30
50
$3.23
100
$3.20
250
$3.17
500
$3.16
1,000
$3.15
2,500
$3.14
5,000 +
$3.13
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes

Accessories

1834369

Cable housing - pitch: 3.81 mm - number of positions: 4 - dimension a: 17.63 mm - color: g ...

1205037

Screwdriver - slot-headed - VDE insulated - size: 0.4 x 2.5 x 80 mm - 2-component grip - w ...
