1786284 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1786284

PCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 13 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

This PCB connector, part number 1786284 from PHOENIX CONTACT, is designed for reliable electrical connections on printed circuit boards. It has a nominal current rating of 12 A and a rated voltage of 320 V (III/2). The connector accommodates a nominal cross-section of 2.5 mm² and features 13 positions with a 5.08 mm pitch. The connection method is via a screw connection with a tension sleeve for secure and stable connectivity. The connector is color-coded green and has a contact surface with a tin finish for enhanced conductivity and corrosion resistance. Ideal for various electronic applications requiring high-quality PCB connections.

Search Keywords: 1786284

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1786284
Alias/AKA:
IC-2-5/13-ST-5-08
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50

FREQUENTLY ASKED QUESTIONS

Is 1786284 RoHS compliant?

Yes, 1786284 is RoHS compliant.

What is the lead time for 1786284?

The standard lead time for 1786284 is approximately 5 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 32

Can Ship immediately

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
1
$21.73
5
$19.49
10
$15.80
25
$15.65
50
$15.50
100
$15.46
250 +
$15.42
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
