1780002 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1780002

PCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 4 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1780002 is a PCB connector designed for reliable and secure electrical connections. With a nominal current rating of 12 A and a rated voltage of 320 V (III/2), it is suitable for various applications. The connector has 4 positions and a pitch of 5.08 mm, allowing for easy installation and connectivity. It features a screw connection with tension sleeve, ensuring a strong and durable connection. The connector comes in a vibrant green color and has a tin contact surface, providing excellent conductivity and corrosion resistance. Its nominal cross section of 2.5 mm² makes it suitable for medium-sized electrical wires. Overall, this PCB connector from PHOENIX CONTACT is a reliable choice for any electrical project.

Search Keywords: 1780002

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1780002
Alias/AKA:
MSTBT-2-5/-4-ST-5-08
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
4
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is 1780002 RoHS compliant?

Yes, 1780002 is RoHS compliant.

What is the lead time for 1780002?

The standard lead time for 1780002 is approximately 12 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 242

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
5
$6.03
25
$4.99
100
$4.90
300
$4.88
500
$4.87
1,000
$4.86
2,500
$4.85
5,000 +
$4.84
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
