1751189 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1751189

PCB terminal block - nominal current: 9 A - rated voltage (III/2): 320 V - nominal cross section: 1.5 mm² - pitch: 5.08 mm - number of positions: 4 - connection method: Push-in spring connection - mounting: Wave soldering - conductor/PCB connection direction: 45 ° - color: green - Pin layout: Linear double pinning - Solder pin [P]: 3.4 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1751189 is a high-quality PCB terminal block designed for efficient electrical connections in various applications. With a nominal current rating of 9A and a rated voltage of 320V, this terminal block offers reliable performance and durability.Featuring a push-in spring connection method, this terminal block ensures secure and quick wire connections. It has a nominal cross section of 1.5mm², providing ample space for wire insertion. The pitch of 5.08mm allows for easy placement on the PCB.With 4 positions available, this terminal block can accommodate multiple wires, making it versatile for various circuit configurations. The mounting method is wave soldering, ensuring a stable and secure connection to the PCB.The conductor/PCB connection direction is set at 45°, allowing for convenient routing and organization of wires. The green color of the terminal block adds visibility and ease of identification.The pin layout of this terminal block is linear double pinning, enabling efficient connectivity. Additionally, the solder pin has a length of 3.4mm, providing a strong and reliable solder joint.Overall, the PHOENIX CONTACT part 1751189 is a high-performance PCB terminal block that offers excellent electrical connectivity and durability, making it an ideal choice for various industrial and commercial applications.

Search Keywords: 1751189

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1751189
Alias/AKA:
SPTA-1-5/-4-5-08
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
5.08 mm
Number of Circuits:
4
Maximum Voltage Rating:
320 V
Maximum Current Rating:
9 A
Wire Size:
16-24 AWG
Operating Temperature:
-40 to 100 °C

FREQUENTLY ASKED QUESTIONS

Is 1751189 RoHS compliant?

Yes, 1751189 is RoHS compliant.

What is the lead time for 1751189?

The standard lead time for 1751189 is approximately 36 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 200

Can Ship immediately

On Order: 200   can ship 6/7/27

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 36 Weeks

Price (USD)

Qty
Unit Price
50
$2.80
100
$2.63
250
$2.48
500
$2.35
1,000
$2.31
2,500
$2.25
5,000
$2.22
7,500 +
$2.20
Supplier's Standard Package
