MLSS156-18-C by pancon connectors
Pancon Connectors Authorized Distributor

MLSS156-18-C

Header Connector, pcb Mount, recept, 18 Contacts, pin, 0.156 Pitch, pc Tail Terminal ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The MLSS156-18-C is an MAS-CON Series 156 header connector designed for reliable interconnection in compact electronic assemblies. This 18-position connector features a 3.69 mm pitch spacing, 180° breakable design with integrated locking mechanism, and operates without polarization for flexible mating configurations. The connector has a pin detail tolerance of ±0.018 inches (0.46 mm) at the tips and allows up to 3° maximum twist in either direction for alignment flexibility. Dimension A for the 18-position configuration is 2.808 inches (71.32 mm), with Dimension B at 2.652 inches (67.36 mm). This connector is commonly used in industrial control systems, telecommunications equipment, and modular electronic devices where space-efficient, secure interconnection is required.

Search Keywords: MLSS15618C

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Pancon Connectors
Part No:
MLSS156-18-C
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100

FREQUENTLY ASKED QUESTIONS

Is MLSS156-18-C RoHS compliant?

Yes, MLSS156-18-C is RoHS compliant.

What is the lead time for MLSS156-18-C?

The standard lead time for MLSS156-18-C is approximately 18 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 825

Can Ship immediately

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 750

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
25
$3.54
250
$3.53
500
$3.52
750
$3.51
1,500
$1.86
2,250
$1.31
3,000 +
$1.28
