EVQ-P2202M by panasonic
Image is representational - see mfr. specs

EVQ-P2202M

Panasonic

The EVQ-P2202M is a 4.7 mm x 3.5 mm surface-mount Light Touch Switch featuring a short push travel and a 1.6 N operating force. ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The EVQ-P2202M is a snap-action, short push travel Light Touch Switch in a compact 4.7 mm x 3.5 mm SMD package. This switch has a height of 2.1 mm, requires a 1.6 N operating force, and provides a travel of 0.25 mm. It is designed for high reliability with an operational life of 1,000,000 cycles and operates over a temperature range of -40 °C to +85 °C. Key electrical characteristics include a rating from 10 μA at 2 VDC to 20 mA at 15 VDC and a maximum contact resistance of 100 mΩ. Common applications include operation switches for portable electronic equipment, keyless entry systems, and car audio equipment.

Search Keywords: EVQP2202M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic
Part No:
EVQ-P2202M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
JP
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
4000
Package Type:
Reel
Dimension:
3.5 x 5.5 x 2.1 mm
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Button
Operating Force:
1.6 N
Contact Rating @ Voltage:
0.02@15VDC A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
J-Lead
Seal:
N/A
Seal Location:
N/A

IN STOCK: 9,760

Ships today, if you order in

Minimum Order Quantity: 1000

Factory Lead-Time 7 Weeks

Qty
Unit Price
1,000
$0.3184
4,000
$0.3122
8,000
$0.3106
12,000
$0.3091
16,000
$0.3075
28,000
$0.3060
52,000 +
$0.3045
Reel Package
