Image is representational - see mfr. specs

ETQ-P3M2R2KVP

The ETQ-P3M2R2KVP is an automotive-grade, surface-mount power choke coil with a 2.2 μH inductance, designed for high-reliability applications. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The ETQ-P3M2R2KVP is an automotive-grade power choke coil from the PCC-M0530M-LP series, designed for power conversion and filtering circuits. It provides a nominal inductance of 2.2 μH with a ±20% tolerance and features a typical DC resistance (DCR) of 20.0 mΩ. The inductor supports a temperature-rise rated current of 6.3 A and a saturation current of 10.1 A, operating across a temperature range of -55°C to +155°C. Constructed with a metal composite core in a shielded, low-profile (3.0 mm max height) package, it offers high heat resistance and efficiency. Its AEC-Q200 compliance and high reliability make it ideal for DC/DC converters and noise filters in strenuous automotive environments.

Product Highlights:

Potential Applications:

Search Keywords: ETQP3M2R2KVP

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Panasonic

Part No:

ETQ-P3M2R2KVP

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504508000

COO:

ECCN:

EAR99
