Image is representational - see mfr. specs

EEE-TP1K681M

The EEE-TP1K681M is a surface-mount, AEC-Q200 compliant aluminum electrolytic capacitor with a capacitance of 680 µF and a rated voltage of 80 V. ...

Datasheet

RoHS Compliant

Reel Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The EEE-TP1K681M is a surface-mount aluminum electrolytic capacitor from the medium-size TP series, designed for high-temperature, lead-free reflow applications. It offers a capacitance of 680 µF with a ±20% tolerance and a rated voltage of 80 V. Key features include a low ESR of 0.068 Ω at 100 kHz, a high ripple current capability of 2600 mA rms at 125 °C, and an endurance rating of 4000 hours at 125 °C. Being AEC-Q200 and RoHS compliant, this capacitor is ideal for demanding applications requiring high reliability and performance in high-temperature environments, such as automotive electronics.

Product Highlights:

Potential Applications:

Search Keywords: EEETP1K681M

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Panasonic

Part No:

EEE-TP1K681M

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8532290040

COO:

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
