ECH-U1H152JX5 by panasonic
Image is representational - see mfr. specs

ECH-U1H152JX5

Panasonic

The ECH-U1H152JX5 is a stacked metallized PPS film chip capacitor with a capacitance of 0.0015 µF, a rated voltage of 50 VDC, and a ±5% tolerance. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ECH-U1H152JX5 is a stacked metallized PPS film chip capacitor with a 0.0015 µF capacitance. It is designed for reflow soldering and operates with a rated voltage of 50 VDC and a capacitance tolerance of ±5%. This component features a low dissipation factor of 0.6% or less at 1 kHz and a high insulation resistance of 3000 MΩ or greater. It is housed in a compact 2.0 x 1.25 x 0.9 mm package and operates over a wide temperature range of -55 °C to +125 °C. Common applications for this RoHS-compliant capacitor include time-constant circuits, filtering, oscillation, and resonance.

Search Keywords: ECHU1H152JX5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic
Part No:
ECH-U1H152JX5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8532250055
COO:
JP
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
3000
Package Type:
REEL
Dielectric:
PPS
Voltage:
50 VDC
Capacitance Value:
0.0015 uF
Tolerance:
5 %
Mounting:
Surface Mount
Termination Style:
N/R
Size:
2 x 1.25 x 0.9 mm

IN STOCK: 9,000

Can Ship immediately

Minimum Order Quantity: 3000

Multiple: 3000

Factory Lead-Time 12 Weeks

Qty
Unit Price
3,000
$0.1546
6,000
$0.1455
9,000
$0.1408
12,000
$0.1370
27,000
$0.1318
51,000
$0.1274
102,000 +
$0.1260
Reel Package
