TX2SA-5V-Z by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

TX2SA-5V-Z

Signal Relay 5VDC 2A DPDT(15x9.4x8.4)mm SMD Medical ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT TX2SA-5V-Z is a compact, high-performance signal relay designed for medical applications. With a voltage rating of 5VDC and a current rating of 2A, this DPDT relay is ideal for electronic devices that require reliable signal switching. Its small size (15x9.4x8.4mm) and surface mount design make it easy to integrate into compact medical equipment. The PANASONIC EW/AROMAT TX2SA-5V-Z is crafted using high-quality materials, ensuring long-lasting performance and exceptional durability. Trust this reliable signal relay to provide precise and efficient signal control in your medical devices.

Search Keywords: TX2SA5VZ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TX2SA-5V-Z
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
500
Relay Construction:
Non-Latching12534
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
2 A
Mounting:
Surface Mount12526
Operating Temperature:
-40 to 85 °C
Dimension:
15 x 9.4 x 8.2 mm
Termination Style:
Gull Wing12536
Coil Current:
28.1 mA
Contact Form:
2 Form C12515

FREQUENTLY ASKED QUESTIONS

What replaces TX2SA-5V-Z?

The recommended replacement for TX2SA-5V-Z is TX2SA-5V-X from Panasonic Electronic Components, available from Master Electronics.

Is TX2SA-5V-Z RoHS compliant?

Yes, TX2SA-5V-Z is RoHS compliant.

What is the lead time for TX2SA-5V-Z?

The standard lead time for TX2SA-5V-Z is approximately 52 weeks. In-stock quantities ship from Master Electronics.

  Different packaging options available.  See Alternatives
  Possible Replacement options available.  See Alternatives

IN STOCK: 9,243

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 52 Weeks

Price (USD)

Qty
Unit Price
5
$4.22
25
$3.80
50
$2.93
100
$2.59
250
$2.44
500
$2.33
1,000 +
$1.98
