TQ2SA-L-4.5V by panasonic electronic components

TQ2SA-L-4.5V

Panasonic Electronic Components

Signal Relay 4.5VDC 2A DPDT(14x11.5x5.6)mm SMD ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT part TQ2SA-L-4.5V is a high-quality signal relay designed for reliable switching in various applications. With a compact size of 14x11.5x5.6mm, this surface-mount device (SMD) is perfect for space-constrained electronic circuits.Operating at a voltage of 4.5VDC, this relay is capable of handling a current of up to 2A. It features a double-pole double-throw (DPDT) configuration, providing versatile and efficient switching capabilities.The PANASONIC TQ2SA-L-4.5V signal relay exhibits excellent performance, ensuring stable and low-resistance contact. Its SMD package allows for easy and secure installation on the circuit board.This reliable and durable relay is suitable for various applications, including telecommunications, automotive electronics, industrial controls, and more. Its high-quality construction and excellent electrical characteristics make it an ideal choice for demanding electronic systems.Overall, the PANASONIC EW/AROMAT part TQ2SA-L-4.5V is a compact, high-performing signal relay that guarantees efficient switching and durability in a range of applications.

Search Keywords: TQ2SAL45V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TQ2SA-L-4.5V
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Latching Single Coil
AC Coil Voltage:
N/A
DC Coil Voltage:
4.5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
14 x 11.5 x 5.6 mm
Termination Style:
Gull Wing
Coil Current:
15.6 mA
Contact Form:
2 Form C

IN STOCK: 0

On Order: 1,000   can ship 12/10/25

Minimum Order: 50

Multiple: 50

Factory Lead-Time 21 Weeks

Qty
Unit Price
50
$4.87
100
$4.14
250
$3.74
500
$3.53
1,000
$3.28
2,500
$3.27
5,000
$3.25
7,500 +
$3.23
Suppliers Standard Package
