TQ2-9V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

TQ2-9V

Signal Relay 9VDC 1A DPDT(14x9x5)mm THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT part TQ2-9V is a compact and reliable signal relay designed for various electronic applications. With a coil voltage of 9VDC and a contact rating of 1A, this DPDT (Double Pole Double Throw) relay is capable of efficiently switching or routing signals in electronic circuits. Its compact dimensions of 14x9x5mm make it suitable for space-constrained applications. The Through-Hole Technology (THT) allows for easy installation and secure soldering onto PCBs. Trust the PANASONIC EW/AROMAT TQ2-9V relay for its exceptional quality and performance for your signal switching needs.

Search Keywords: TQ29V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TQ2-9V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
9 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
1 A
Mounting:
Through Hole12526
Operating Temperature:
-40 to 70 °C
Dimension:
14 x 9 x 5 mm
Termination Style:
PC Pin12536
Coil Current:
15.5 mA
Contact Form:
2 Form C12515

FREQUENTLY ASKED QUESTIONS

Is TQ2-9V RoHS compliant?

Yes, TQ2-9V is RoHS compliant.

What is the lead time for TQ2-9V?

The standard lead time for TQ2-9V is approximately 56 days. In-stock quantities ship from Master Electronics.

IN STOCK: 576

Can Ship immediately

On Order: 4,000   can ship 8/18/27

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 56 Weeks

Price (USD)

Qty
Unit Price
50
$1.91
100
$1.89
250
$1.83
500
$1.78
1,000
$1.76
2,500
$1.75
5,000
$1.74
7,500 +
$1.73
Supplier's Standard Package
