ST1-DC12V-F by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

ST1-DC12V-F

Power Relay 12VDC 8A SPST-NO/SPST-NC(31x14x11.3)mm THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT ST1-DC12V-F is a high-quality power relay designed for various electrical applications. It operates at 12VDC and has a contact rating of 8A. This relay features a single pole, single throw normally open and normally closed configuration, making it versatile for both SPST-NO and SPST-NC applications. With its compact dimensions of 31x14x11.3mm, this through-hole technology (THT) relay is easy to integrate into any electronic circuit or system. It offers reliable performance, ensuring smooth power switching and efficient signal control. Whether used in automotive, industrial, or other electronic equipment, the PANASONIC EW/AROMAT ST1-DC12V-F power relay is a dependable and space-saving solution for your 12VDC power control needs.

Search Keywords: ST1DC12VF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
ST1-DC12V-F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO,SPST-NC
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 60 °C
Coil Resistance:
600 Ohm

FREQUENTLY ASKED QUESTIONS

Is ST1-DC12V-F RoHS compliant?

Yes, ST1-DC12V-F is RoHS compliant.

What is the lead time for ST1-DC12V-F?

The standard lead time for ST1-DC12V-F is approximately 16 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1,000

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
5
$11.05
25
$9.93
50
$9.51
100
$9.11
250
$8.66
500
$8.36
1,000 +
$8.07
Supplier's Standard Package
