S2EB-24V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

S2EB-24V

Power Relay 24VDC 4A DPST-NO/DPST-NC(28x12x10)mm THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT S2EB-24V is a power relay designed to provide reliable switching performance in various electrical applications. With a coil voltage of 24VDC, this relay is capable of handling a current of up to 4A. It features a DPST-NO (Double Pole Single Throw Normally Open) and DPST-NC (Double Pole Single Throw Normally Closed) configuration, allowing for versatile switching options. The compact size of 28x12x10mm makes it suitable for through-hole mounting installations. This power relay is an excellent choice for controlling various power circuits with precision and efficiency.

Search Keywords: S2EB24V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
S2EB-24V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPST-NO,DPST-NC
Maximum Current Rating:
3DC,4AC A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 65 °C
Coil Resistance:
2.85 KOhm

FREQUENTLY ASKED QUESTIONS

What replaces S2EB-24V?

The recommended replacement for S2EB-24V is S2E-24V from Panasonic Electronic Components, available from Master Electronics.

Is S2EB-24V RoHS compliant?

Yes, S2EB-24V is RoHS compliant.

What is the lead time for S2EB-24V?

The standard lead time for S2EB-24V is approximately 24 days. In-stock quantities ship from Master Electronics.

IN STOCK: 912

Ships today, if you order in

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
1
$38.59
5
$31.27
10
$30.74
25
$29.83
50
$29.76
100
$29.69
250 +
$29.61
Supplier's Standard Package
