JW2SN-B-DC5V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

JW2SN-B-DC5V

Power Relay 5VDC 5A DPDT (( 28.6mm 12.8mm 20mm)) Through Hole ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

JW2SN-B-DC5V is a 2 Form C power relay designed for switching applications in home appliances, office machines, and industrial equipment. It features a 5 V DC rated coil voltage, sealed protective construction, and Class B coil insulation. The relay offers a standard contact capacity of 5 A with switching capabilities of 5 A at 250 V AC or 5 A at 30 V DC resistive load. With compact dimensions of 12.8 mm width × 28.6 mm length × 20 mm height, this miniature relay is suitable for PCB mounting applications requiring reliable power switching performance.

Search Keywords: JW2SNBDC5V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
JW2SN-B-DC5V
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536410020
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
47 Ohm

FREQUENTLY ASKED QUESTIONS

Is JW2SN-B-DC5V RoHS compliant?

No, JW2SN-B-DC5V is not RoHS compliant.

What is the lead time for JW2SN-B-DC5V?

The standard lead time for JW2SN-B-DC5V is approximately 24 weeks. In-stock quantities ship from Master Electronics.

  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 407

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
5
$4.25
50
$3.79
100
$3.65
300
$3.43
500
$3.31
1,000
$1.90
2,500
$1.80
5,000 +
$1.72
Supplier's Standard Package
