JW1AFSN-DC24V-F by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

JW1AFSN-DC24V-F

Power Relay 24VDC 10A SPST-NO(28.6x12.8x20)mm THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT JW1AFSN-DC24V-F is a reliable and high-quality power relay designed for various electronic applications. Rated at 24VDC with a maximum current of 10A, this SPST-NO (Single Pole Single Throw - Normally Open) relay provides excellent switching capabilities for your electrical circuits. With compact dimensions of 28.6x12.8x20mm, it can be easily mounted through-hole (THT) on PCBs or other suitable surfaces. This PANASONIC EW/AROMAT relay is an essential component for ensuring proper power management and control in your projects.

Search Keywords: JW1AFSNDC24VF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
JW1AFSN-DC24V-F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Relay Construction:
Non-Latching
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 60 °C
Coil Resistance:
1.1 KOhm

FREQUENTLY ASKED QUESTIONS

Is JW1AFSN-DC24V-F RoHS compliant?

Yes, JW1AFSN-DC24V-F is RoHS compliant.

What is the lead time for JW1AFSN-DC24V-F?

The standard lead time for JW1AFSN-DC24V-F is approximately 20 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 750

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
100
$1.28
300
$1.25
500
$1.22
1,000
$1.21
2,500
$1.20
5,000
$1.19
7,500
$1.18
10,000 +
$1.17
