JTN1AS-TMP-F-DC12V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

JTN1AS-TMP-F-DC12V

Power Relay 12VDC 30A SPST-NO(32.2x27.4x27.9)mm Top Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT part JTN1AS-TMP-F-DC12V is a high-quality power relay designed for various electrical applications. With a compact size of 32.2x27.4x27.9mm, it can easily be installed on the top mount of your equipment. Perfect for handling high currents, this relay operates at 12VDC and can handle up to 30A of power. It features a single pole, single throw normally open (SPST-NO) configuration, ensuring reliable control and connectivity. Trust this PANASONIC EW/AROMAT power relay to efficiently manage your electrical system.

Search Keywords: JTN1ASTMPFDC12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
JTN1AS-TMP-F-DC12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO10703
Mounting:
Top Mount10716
Termination Style:
Quick Connect/PC Pin10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-55 to 85 °C
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is JTN1AS-TMP-F-DC12V discontinued?

Yes, JTN1AS-TMP-F-DC12V from Panasonic Electronic Components is discontinued. Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

What replaces JTN1AS-TMP-F-DC12V?

The recommended replacement for JTN1AS-TMP-F-DC12V is JT1AE-TMP-B-DC12V from Panasonic Electronic Components, available from Master Electronics.

Is JTN1AS-TMP-F-DC12V RoHS compliant?

Yes, JTN1AS-TMP-F-DC12V is RoHS compliant.

What is the lead time for JTN1AS-TMP-F-DC12V?

The standard lead time for JTN1AS-TMP-F-DC12V is approximately 40 weeks. In-stock quantities ship from Master Electronics.
