JQ1AP-B-18V-F by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

JQ1AP-B-18V-F

Electromechanical Relay 18VDC 1.62KOhm 10(NO)/3(NC)A SPST-NO (20x10x16)mm THT Power Relay

View Datasheet Ask the Datasheet
RoHS Compliant
Bulk Packaging
Accessories
Request Programming Quote
Discontinued & Replaced
Certificate of Compliance

DESCRIPTION

Electromechanical Relay 18VDC 1.62KOhm 10(NO)/3(NC)A SPST-NO (20x10x16)mm THT Power Relay

Search Keywords: JQ1APB18VF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
JQ1AP-B-18V-F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
Bulk
Relay Construction:
Non-Latching
DC Coil Voltage:
18 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
10(NO)/3(NC) A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
1.62 KOhm
Life Cycle:
Discontinued & Replaced

FREQUENTLY ASKED QUESTIONS

Is JQ1AP-B-18V-F discontinued?

Yes, JQ1AP-B-18V-F from Panasonic Electronic Components is discontinued (end-of-life September 2016). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

What replaces JQ1AP-B-18V-F?

The recommended replacement for JQ1AP-B-18V-F is ALQ318 from Panasonic Electronic Components, available from Master Electronics.

Is JQ1AP-B-18V-F RoHS compliant?

Yes, JQ1AP-B-18V-F is RoHS compliant.

What is the lead time for JQ1AP-B-18V-F?

The standard lead time for JQ1AP-B-18V-F is approximately 143 weeks. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 31

Can Ship immediately

Minimum Order Quantity: 10

Price (USD)

Qty
Unit Price
10
$2.93
50
$2.62
100
$2.61
300
$2.52
500
$2.46
1,000
$2.45
2,500
$2.40
5,000 +
$2.38
