DSP2A-DC5V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

DSP2A-DC5V

Power Relay 5VDC 5A DPST-NO(20.2x11x10.5)mm THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT DSP2A-DC5V is a compact power relay designed for applications requiring a reliable switching device. This relay operates at 5VDC with a 5A contact rating, making it suitable for a variety of low-power control and automation tasks. The relay features a DPST-NO (Double Pole Single Throw - Normally Open) configuration and is through-hole mounted (THT) with dimensions of 20.2x11x10.5mm, making it easy to integrate into your circuit design. Trust the PANASONIC EW/AROMAT DSP2A-DC5V for efficient and dependable performance in your electronic projects.

Search Keywords: DSP2ADC5V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
DSP2A-DC5V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Relay Construction:
Non-Latching
DC Coil Voltage:
5 V
Contact Arrangement:
DPST-NO
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 60 °C
Coil Resistance:
83 Ohm

FREQUENTLY ASKED QUESTIONS

Is DSP2A-DC5V RoHS compliant?

Yes, DSP2A-DC5V is RoHS compliant.

What is the lead time for DSP2A-DC5V?

The standard lead time for DSP2A-DC5V is approximately 20 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1,016

Can Ship immediately

On Order: 1,300   can ship 1/13/27

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
50
$3.13
100
$3.03
250
$2.98
500
$2.97
1,000
$2.96
2,500 +
$2.95
