DS4E-S-DC12V

General Purpose Relay - 4PDT (4 Form C) - 12VDC Coil - 2A contact - 250VAC/220VDC Switching - Non Latching Coil - PC Pin Termination. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

The DS4E-S-DC12V from Panasonic Electronic Components is four pole double throw 4PDT (4 Form C) general purpose relay with non latching coil and PC pin termination. This fully sealed relay has 12VDC coil voltage, 2A contact current and 250VAC/220VDC switching voltage. Operating temperature range is from -40°C to 70°C.

Search Keywords: DS4ESDC12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
DS4E-S-DC12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Package Type:
Box
Relay Construction:
Non-Latching
DC Coil Voltage:
12 V
Contact Arrangement:
4PDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
35.24 x 9.9 x 9.9 mm
Termination Style:
PC Pin
Coil Current:
16.7 mA
Contact Form:
4 Form C
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is DS4E-S-DC12V discontinued?

Yes, DS4E-S-DC12V from Panasonic Electronic Components is discontinued. Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is DS4E-S-DC12V RoHS compliant?

Yes, DS4E-S-DC12V is RoHS compliant.

What is the lead time for DS4E-S-DC12V?

The standard lead time for DS4E-S-DC12V is approximately 9 weeks. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 440

Can Ship immediately

Price (USD)

Qty
Unit Price
1
$159.00
5
$148.00
10
$139.00
25
$127.00
50
$118.00
100
$107.00
250
$89.00
500 +
$64.00
Supplier's Standard Package
