CP1A-12V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

CP1A-12V

The CP1A-12V is a compact, PC board mount automotive relay with a 1 Form A contact arrangement and a 12V DC coil. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The CP1A-12V is a compact automotive relay designed for PC board mounting. It operates with a nominal coil voltage of 12V DC and features a 1 Form A contact configuration. This relay has a nominal switching capacity of 20A at 14V DC and can carry a continuous current of 25A for one hour at 85°C. Its sealed construction ensures reliability in harsh environments with an operating temperature range of -40°C to +85°C. Common applications include automotive power systems like power windows, automatic door locks, sunroofs, and defoggers.

Search Keywords: CP1A12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CP1A-12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Max Contact Current:
20A
Coil Voltage:
12 VDC
Coil Current:
53.3 mA
Coil Resistance:
225 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
7.2 VDC
Must Release Voltage:
1 VDC
Operate Time:
10 ms
Seal:
Sealed
Mounting:
Through Hole
Termination Style:
PC Pin
Dimension:
14 x 13 x 9.5 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Tube

FREQUENTLY ASKED QUESTIONS

Is CP1A-12V RoHS compliant?

Yes, CP1A-12V is RoHS compliant.

What is the lead time for CP1A-12V?

The standard lead time for CP1A-12V is approximately 25 days. In-stock quantities ship from Master Electronics.

IN STOCK: 97

Can Ship immediately

On Order: 3,000   can ship 10/14/26

Minimum Order Quantity: 10

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
10
$2.83
100
$2.56
250
$2.46
500
$2.36
1,000
$2.25
3,000
$2.24
5,000
$2.23
8,000 +
$2.22
Supplier's Standard Package
