CB1-R-M-12V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

CB1-R-M-12V

Relays 12VDC 89.5Ohm 40(NO)/30(NC)A SPDT(30mm 22mm 52mm) Bracket Automotive Relay Automotive ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

Upgrade your automotive electrical system with the PANASONIC EW/AROMAT CB1-R-M-12V relay. This high-quality component is designed for 12VDC applications, featuring a low resistance of 89.5Ohm and a robust SPDT configuration with 40(NO)/30(NC)A contact ratings. The compact design, measuring 30mm x 22mm x 52mm, is supported by a sturdy bracket for secure installation. Trust this automotive relay to deliver reliable performance and seamless operation in your vehicle's electrical system. Ideal for a wide range of automotive applications, this PANASONIC EW/AROMAT relay is a must-have for any automotive enthusiast or professional.

Search Keywords: CB1RM12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CB1-R-M-12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Contact Form:
SPDT (1 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
40A (NO) / 30A (NC)
Coil Voltage:
12 VDC
Coil Current:
134 mA
Coil Resistance:
89.5 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
7 VDC
Must Release Voltage:
4.2 VDC
Operate Time:
15 ms
Seal:
Sealed
Mounting:
Bracket Mount
Termination Style:
0.25 Quick Connect
Dimension:
30 x 22 x 52 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton

FREQUENTLY ASKED QUESTIONS

Is CB1-R-M-12V RoHS compliant?

Yes, CB1-R-M-12V is RoHS compliant.

What is the lead time for CB1-R-M-12V?

The standard lead time for CB1-R-M-12V is approximately 24 days. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 1,725   can ship 12/23/26
On Order: 1,000   can ship 12/31/26

Minimum Order Quantity: 5

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
5
$6.084
50
$5.150
200
$4.885
400
$4.691
600
$4.609
1,000
$4.450
2,600
$4.439
5,000 +
$4.428
Supplier's Standard Package
