CB1A-D-12V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

CB1A-D-12V

Electromechanical Relay 12VDC 103Ohm 40A SPST-NO (26x22x36)mm Plug-In Automotive Relay ...

View Datasheet Ask the Datasheet
RoHS Compliant
Bulk Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

CB1A-D-12V is an automotive relay featuring a 12V DC nominal coil voltage with an integrated diode inside and 1 Form A contact arrangement. The relay incorporates ISO (International Organization for Standardization) terminal arrangement with solder-plated terminals, and is designed with a compact form factor of 22 × 26 mm base area. It delivers high switching capacity of 40 A at resistive loads and operates reliably across a wide ambient temperature range. The integrated diode provides transient suppression, making it suitable for automotive engine compartment applications and other harsh environments where electromagnetic switching protection is essential.

Search Keywords: CB1AD12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CB1A-D-12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Bulk
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Max Contact Current:
40A
Coil Voltage:
12 VDC
Coil Current:
117 mA
Coil Resistance:
103 Ohm
Coil Suppression:
Diode
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
7 VDC
Must Release Voltage:
4.2 VDC
Operate Time:
15 ms
Seal:
Sealed
Mounting:
Connector
Termination Style:
0.25 Quick Connect
Dimension:
26 x 22 x 36 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is CB1A-D-12V discontinued?

Yes, CB1A-D-12V from Panasonic Electronic Components is discontinued (end-of-life March 2015). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

What replaces CB1A-D-12V?

The recommended replacement for CB1A-D-12V is CB1AE-D-12V from Panasonic Electronic Components, available from Master Electronics.

Is CB1A-D-12V RoHS compliant?

Yes, CB1A-D-12V is RoHS compliant.

What is the lead time for CB1A-D-12V?

The standard lead time for CB1A-D-12V is approximately 18 days. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock
  Possible Replacement options available.  See Alternatives

IN STOCK: 336

Can Ship immediately

Minimum Order Quantity: 10

Price (USD)

Qty
Unit Price
10
$3.574
25
$3.396
50
$3.226
100
$3.065
500
$2.911
1,000 +
$2.570
