CA1A-12V-N-5

Power Relay 12VDC 150A SPST-NO (21.5mm 17.4mm 54.5mm) Automotive ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

CA1A-12V-N-5 is a small-size automotive power relay designed for space-constrained applications in motorcycles, automobiles, and agricultural equipment. This 1 Form A relay features a 12V DC coil voltage with screw-mounting type installation, measuring 21.5 mm (length) × 14.4 mm (width) × 37 mm (height) and weighing approximately 19 g. The relay delivers a nominal switching capacity of 20 A at 12V DC with a maximum carrying current of 20 A continuous, utilizing silver alloy (cadmium-free) contacts with typical initial contact resistance of 3 mO. It exhibits superior inrush current handling capability of up to 120 A (max. 0.1 s) and provides an electrical life of minimum 105 operations at nominal switching capacity. The relay is sealed with epoxy resin per JIS D 0203 S2 waterproof standard and operates reliably across ambient temperatures from -30°C to +80°C, making it ideal for demanding automotive applications including motor control, air conditioning systems, and halogen lamp switching.

Search Keywords: CA1A12VN5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CA1A-12V-N-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410005
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Relay Construction:
Non-Latching
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Operating Temperature:
-30 to 80 °C
Termination Style:
Screw Terminal
