AXK880145WG by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

AXK880145WG

Conn Board to Board PL 80 POS 0.4mm Solder ST SMD T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

AXK880145WG is a narrow pitch board-to-board header connector designed for reliable interconnection in compact electronic assemblies. This connector features a 0.4 mm pitch with 80 pins and is available in multiple mated heights including 2.0 mm, 2.5 mm, and 3.0 mm configurations. It utilizes Panasonic's "Tough Contact" construction for high contact reliability and strong resistance to adverse environments, along with impact dispersion keys inside the body to disperse shocks when dropped. The connector is RoHS compliant and designed without soldering terminals. Common applications include board-to-board and board-to-FPC connections in space-constrained electronic devices where high reliability and shock resistance are required.

Search Keywords: AXK880145WG

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AXK880145WG
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Type:
Board to Board
Body Orientation:
Straight
Gender:
HDR
Mounting:
Surface Mount
Pitch:
0.4 mm
Number of Contacts:
80
Maximum Voltage Rating:
60,60 VDC|VAC
Maximum Current Rating:
5 A
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is AXK880145WG discontinued?

Yes, AXK880145WG from Panasonic Electronic Components is discontinued (end-of-life March 2021). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is AXK880145WG RoHS compliant?

Yes, AXK880145WG is RoHS compliant.

What is the lead time for AXK880145WG?

The standard lead time for AXK880145WG is approximately 15 weeks. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 4,873

Ships today, if you order in

Minimum Order Quantity: 10

Price (USD)

Qty
Unit Price
10
$1.70
100
$1.52
250
$1.48
500
$1.46
1,000
$1.42
3,000
$1.40
6,000
$1.38
9,000 +
$1.36
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

AXK780147G

Conn Board to Board RCP 80 POS 0.4mm Solder ST SMD T/R
