AQZ104 by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

AQZ104

Solid State Relay 50mA 1.5V DC-IN 0.7A 320V DC-OUT 4-Pin SIL ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

AQZ104 is a PhotoMOS Power 1 Form A solid-state relay designed for DC-only applications requiring high voltage switching capability. It features a maximum load voltage of 400 V DC with a continuous load current rating of 0.7 A, combined with extremely low on-resistance of 0.55 O (maximum) and a peak load current capability of 1.5 A. The device offers high I/O isolation voltage of 2,500 Vrms, low off-state leakage current of maximum 10 µA, and operates reliably across an ambient temperature range of -40°C to +85°C. With its slim SIL4-pin package, low thermoelectric force, and elimination of the need for counter electromotive protection diodes, the AQZ104 is well-suited for traffic signals, measuring instruments, and industrial machine control applications where reliable, noise-free switching is essential.

Search Keywords: AQZ104

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQZ104
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Output Type:
DC
Maximum Output Voltage:
400 V
Maximum Output Current:
0.7 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Through Hole
Circuit Arrangement:
1 Form A
Dimension:
21 x 3.5 x 12.5 mm

FREQUENTLY ASKED QUESTIONS

Is AQZ104 RoHS compliant?

Yes, AQZ104 is RoHS compliant.

What is the lead time for AQZ104?

The standard lead time for AQZ104 is approximately 53 days. In-stock quantities ship from Master Electronics.

IN STOCK: 15

Can Ship immediately

Buy all 15 in-stock or the regular minimum order quantity of 25

On Order: 1,000   can ship 8/9/27

Stock lot only: 15

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 53 Weeks

Price (USD)

Qty
Unit Price
1
$7.601
25
$6.910
50
$6.650
100
$6.400
250
$6.070
500
$5.820
1,000
$4.490
2,500
$4.220
5,000 +
$4.190
Supplier's Standard Package
