AQG22124 by panasonic electronic components
Image is representational - see mfr. specs

AQG22124

Panasonic Electronic Components

The AQG22124 is a slim, zero-cross solid state relay (SSR) featuring a 2A maximum load current and a 24V DC rated control voltage. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AQG22124 is a zero-cross solid state relay designed for 2A load control applications. It operates with a DC control voltage range of 19.2V to 28.8V and switches AC load voltages from 75Vrms to 264Vrms. This SSR features a high dielectric strength of 3,000Vrms between the input and output, a maximum ON-state voltage drop of 1.6V, and a built-in snubber circuit to prevent malfunction from noise. Its slim profile and robust specifications make it ideal for use in household appliances, industrial machinery, healthcare equipment, and microcomputer boards.

Search Keywords: AQG22124

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQG22124
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Output Type:
AC
Maximum Output Voltage:
264 V
Maximum Output Current:
2 A
Output Device:
N/A
Input Type:
DC
Input Voltage:
28.8 V
Mounting:
Through Hole
Circuit Arrangement:
N/A
Dimension:
24.5(Max) x 4.5(Max) x 20.5(Max) mm

IN STOCK: 200

Ships today, if you order in

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 14 Weeks

Qty
Unit Price
20
$3.89
60
$3.80
100
$3.67
260
$3.47
500
$3.36
1,000
$3.24
2,500
$3.23
5,000 +
$3.21
Suppliers Standard Package
