PN2222ABU
The PN2222A is a general-purpose NPN silicon transistor for amplification and switching applications. ...
DESCRIPTION
The PN2222ABU is a general-purpose NPN silicon transistor designed for medium-current amplification and switching. It features a maximum collector-emitter voltage of 40 V, a continuous collector current rating of 600 mA, and a total device dissipation of 625 mW. This device provides a minimum current-gain-bandwidth product of 300 MHz and a DC current gain (hFE) between 100 and 300 at a collector current of 150 mA. Due to its balanced specifications, the PN2222ABU is widely used in driver stages, low-power output stages, and various signal processing circuits.
Search Keywords: PN2222ABU
SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Is PN2222ABU discontinued?
Yes, PN2222ABU from Onsemi is discontinued (end-of-life June 2010). Master Electronics is an authorized reseller and may have remaining stock or a recommended replacement for it.
Is PN2222ABU RoHS compliant?
Yes, PN2222ABU is RoHS compliant.
What is the lead time for PN2222ABU?
The standard lead time for PN2222ABU is approximately 25 days. In-stock quantities ship from Master Electronics.
IN STOCK: 116,752
Can Ship immediately
Minimum Order Quantity: 500
Factory Lead-Time 25 Weeks
Price (USD)
Datasheet
Product Change Notification
