NTGD4167CT1G

A complementary Power MOSFET featuring both an N-Channel and a P-Channel device with a 30V drain-source voltage rating in a dual TSOP-6 package. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The NTGD4167CT1G is a complementary Power MOSFET that integrates both an N-Channel and a P-Channel transistor into a single, compact 3x3 mm TSOP-6 package. The N-Channel component features a maximum on-resistance (RDS(on)) of 90 mΩ at a 4.5V gate voltage, while the P-Channel offers an RDS(on) of 170 mΩ at -4.5V. This device utilizes leading-edge trench technology for low on-resistance and has reduced gate charge to improve switching response. With independently connected devices, it provides significant design flexibility for applications such as DC-DC conversion circuits and load/power switching with level shifting.

Search Keywords: NTGD4167CT1G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
NTGD4167CT1G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541290095
COO:
TW
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
3000

FREQUENTLY ASKED QUESTIONS

Is NTGD4167CT1G RoHS compliant?

Yes, NTGD4167CT1G is RoHS compliant.

What is the lead time for NTGD4167CT1G?

The standard lead time for NTGD4167CT1G is approximately 45 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1,183

Can Ship immediately

Buy all 1,183 in-stock or the regular minimum order quantity of 3000

On Order: 6,000   can ship 4/2/27

Stock lot only: 1183

Minimum Order Quantity: 3000

Multiple: 3000

Factory Lead-Time 45 Weeks

Price (USD)

Qty
Unit Price
1
$0.2844
3,000
$0.2585
6,000
$0.2579
9,000
$0.2572
12,000
$0.2566
27,000
$0.2559
51,000
$0.2553
102,000 +
$0.2546
