NDP6060L

The NDP6060L is an N-Channel logic level enhancement mode power field effect transistor designed for low voltage applications. ...

Datasheet

RoHS Non-Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The NDP6060L is a logic level N-Channel enhancement mode power field effect transistor produced using a proprietary, high cell density DMOS technology. It is rated for a drain-source voltage of 60V and a continuous drain current of 48A. Key features include an extremely low on-state resistance of 0.025 Î© at VGS = 5V, a low gate threshold voltage under 2.0V for direct operation from logic drivers, and a high maximum junction temperature rating of 175Â°C. This device is specifically tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulses. It is particularly suited for automotive applications, DC/DC converters, PWM motor controls, and other battery-powered circuits where fast switching and low power loss are critical.

Product Highlights:

Potential Applications:

Search Keywords: NDP6060L

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

onsemi

Part No:

NDP6060L

Unit of Measure:

Per Each

RoHS:

HTS:

8541290095

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
