FDP20N50F by onsemi

FDP20N50F

onsemi

The FDP20N50F is an N-Channel UniFET FRFET MOSFET rated for 500V, 20A, with a maximum on-resistance of 260 mΩ. ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The FDP20N50F is a high-voltage N-Channel UniFET FRFET MOSFET based on planar stripe and DMOS technology. It is designed to reduce on-state resistance, featuring a typical RDS(on) of 210 mΩ at a 10V gate-source voltage, and provide better switching performance. Key characteristics include a low typical gate charge of 50 nC, a low reverse transfer capacitance of 27 pF, and improved dv/dt capability. This 100% avalanche-tested device is suitable for switching power converter applications such as power factor correction (PFC), uninterruptible power supplies (UPS), lighting, and power supplies for LCD/LED/PDP TVs.

Search Keywords: FDP20N50F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
FDP20N50F
Unit of Measure:
Per Each
RoHS:
No
HTS:
8541290095
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50

IN STOCK: 1,180

Can Ship immediately

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 9 Weeks

Qty
Unit Price
50
$2.62
250
$2.26
500
$1.89
1,000
$1.69
2,500
$1.64
5,000
$1.63
7,500
$1.62
10,000 +
$1.61
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
