SS-5 by omron electronics

SS-5

Omron Electronics

Switch Snap Action N.O./N.C. SPDT Pin Plunger 5A 250VAC 1.47N Screw Mount Solder ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Omron SS series are subminiature basic switches. These switches offer high reliability and security. A variety of models are available with operating force ranging from low to high. Pin plunger, hinge, long hinge, simulated roller , hinge roller lever actuators available Solder, quick connect, PCB terminals available Operating force is 0.06N, 0.12N, 1.47N, 0.49N, 0.25N, 0.16N, 0.08N, 0.39N based on ordering Two split springs ensure a high stability and durability Applications Industrial, Power Management, Automation & Process Control, Security

Search Keywords: SS5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
SS-5
RoHS:
Yes
HTS:
8536509040
COO:
ID
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Pin Plunger
Contact Rating @ Voltage:
5@125VAC 14VDC A
Maximum Movement Differential:
0.1 mm
Operating Force:
1.47 N
Termination Style:
Solder
Dimension:
19.8 x 6.4 x 15.3 mm
Body Orientation:
Straight
IP Rating:
IP40

IN STOCK: 28,176

Can Ship immediately

Minimum Order: 25

Factory Lead-Time 26 Weeks

Qty
Unit Price
25
$1.423
100
$1.194
250
$1.156
500
$1.104
1,000
$1.057
2,500
$1.014
5,000
$0.987
7,500 +
$0.972
